Wall Mounted Eyewash with Stainless Steel Bowl

Where space may be a constraint, this unit of wall mounted eyewash fits easily into your workplace. Emergency eyewash works quickly with a simple push of its highly visible handle. Our eyewash spray heads use the soft-flow aerators and automatic pressure compensating valve inbuilt in the spray head assembly.

Certified to ANSI/ISEA Z358.1-2014 Standard.

ANSI Z358.1-2014: Emergency Eyewash and Shower Standard

SKU: EY 5050 SS Category:

Description

PRODUCT DETAILS – WALL MOUNTED EYEWASH WITH STAINLESS STEEL BOWL

Eyewash Bowl – 280mm (11″) bowl using polished stainless steel for long-lasting use and recommended for outdoor installation. For ABS Bowl unit, please check model EY 5050AB.

Eyewash Assembly – Stainless steel with ABS spray heads assembly with twin, soft-flow eyewash heads and instant flip-open protective dust cover. The built-in automatic pressure compensating valve assures safe steady flow under varying water supply conditions. In addition, the spray heads also include a filter to protect users against particles from the water flow which may be damaging to the eyes and face.

Control Valve – To ensure continuous water flow, this unit is using a stainless steel ½’ IPS valve that stays open until manually closed. Other than that, this wall mounted eyewash unit also has a large, highly visible stainless steel push-plate that operates the control valve.

Pipe and Fitting – 1/2″ IPS stainless steel pipe epoxy powder coated with bright yellow colour.

Wall Bracket –  Aluminium wall mounting bracket epoxy powder coated with bright yellow colour and has 3 mounting holes.

Waste – 1 1/4″ IPS tailpiece

Signage – Eyewash



Where space may be a constraint, this unit of wall mounted eyewash unit fits easily into your workplace. Eyewash works quickly with a simple push of its highly visible handle. Our eyewash spray heads use the soft-flow aerators and automatic pressure compensating valve inbuilt in the spray head assembly.

Certified to ANSI/ISEA Z358.1-2014 Standard.

Additional information

Model

EY 5050 SS

Bowl Size

280 mm

Bowl Material

Stainless Steel 304

Nominal Pipe Size

1 inch

Inlet Size

0.5 inch

Flow Rate

At least 15 l/m

Stanchion

Stainless Steel 304

Connecting Fittings

Stainless Steel 304

Control Valve

Stainless Steel 316

Signage

Eyewash

Certification

ANSI Z358.1 & AS 4775

Documents

METHOD-SIRIM-ANSI 358.1 2014 Certificate
