Floor Mounted Eyewash with Stainless Steel Bowl

This floor mounted eyewash unit works very well in the workplace: for both industrial, and laboratory environment. It can be mounted onto a floor and operated by hand using push plate. Our eyewash spray heads use soft-flow aerators and automatic pressure compensating valve.

Certified to ANSI/ISEA Z358.1-2014 Standard.

ANSI Z358.1-2014: Emergency Eyewash and Shower Standard

SKU: EY 5060 SS Category:

Description

PRODUCT DETAILS – FLOOR MOUNTED EYEWASH WITH STAINLESS STEEL BOWL

Eyewash Bowl – 280mm (11″) bowl using polished stainless steel for long-lasting use and recommended for outdoor installation.

Eyewash Assembly – Stainless steel with ABS spray heads assembly with twin, soft-flow emergency eyewash heads and instant flip-open protective dust cover. The built-in automatic pressure compensating valve assures safe steady flow under varying water supply conditions. In addition, the spray heads also include a filter to protect users against particles from the water flow which may be damaging to the eyes and face.

Control Valve – To ensure continuous water flow, this floor mounted eyewash unit is using a 316 stainless steel 1/2″ IPS valve that stays open until manually closed. Other than that, this unit also has a large, highly visible stainless steel push-plate that operates the control valve.

Pipe and Fitting – 1/2″ and 1″ IPS stainless steel pipe epoxy powder coated in bright yellow colour.

Pedestal –  250mm (10″) aluminium pedestal with 3 mounting holes for 9mm bolts. The pedestal is epoxy powder coated in bright yellow colour.

Waste – 1″ IPS tailpiece

Water Supply – 1/2″ IPS

Signage – Eyewash

Option – For unit with foot pedal, please check model EY 5070SS.



Certified to ANSI/ISEA Z358.1-2014 Standard.

Additional information

Model

EY 5060 SS

Bowl Size

280 mm

Bowl Material

Stainless Steel 304

Nominal Pipe Size

1 inch

Inlet Size

0.5 inch

Flow Rate

At least 15 l/m

Stanchion

Stainless Steel 304

Connecting Fittings

Stainless Steel 304

Control Valve

Stainless Steel 316

Signage

Eyewash

Certification

ANSI Z358.1 & AS 4775

Documents

METHOD-SIRIM-ANSI 358.1 2014 Certificate
