Inlet PP Fan with Inbuilt Damper and Motor (VSB 25)

Technology from Italy with over 50 years’ experience and significant investments in Research and Development has enabled this VSB series to provide a high-quality 10″ centrifugal fans.

This series also has ATEX-certified and Explosion Proof versions. Please let us know if you need a consultation with a suitable extraction fan for your fume cupboards.



SKU: VSB 25 Category:

Description

PRODUCT: INLET PP FAN WITH INBUILD DAMPER AND MOTOR (MODEL VSB 25)

Made of injection-moulded polypropylene, this unit is effective for extracting fumes from laboratories, extraction hoods, chemical, pharmaceutical and galvanising works. The centrifugal fans are used especially in situations that require resistance to chemical agents, silent operation and energy saving.

The top features of the VSB series are:

    • Polypropylene is resistant to ultra-violet rays, is tough and is highly resistant to chemical agents, especially organic solvents.
    • The injection-moulded polypropylene fans are statically and dynamically balanced in order to ensure silent and energy-saving operation.
    • All the fans have a circular intake and a flanged rectangular discharge fitted as standard although a round discharge connection can be fitted.
    • These VSB series fans can be adjusted to 8 positions through 360°.
    • All the units have been constructed for outdoor use with nylon or galvanised metal seats.
    • These VSB units can be combined with single-phase, three-phase and EEx-d, units at one or two speeds as supplied by specialised builders.

Additional information

Model

VSB 25

Diameter

250 mm
10 inch

Hose Power

3HP

Voltage

415 V

Speed

2900 RPM

Casing

Polypropylene

Impeller

Polypropylene

Need help? Call us directly at +603 5122 1818 or email us at [email protected]
